产品概述
产品优势
Safe and Reliable
Frame-type main bearing structure provides high engine block rigidity and enhanced safety performance.
Features an internal and external dual-loop water cooling system with an optional water-jacketed exhaust manifold, extending service life with a 12,000-hour overhaul interval.
Powerful Performance
Ample power reserve with a torque reserve reaching 20%-35%.
High-pressure fuel pump, turbocharger, and injectors ensure rapid acceleration and high vessel speeds.
Economical and Fuel-Efficient
Optimized intake and fuel supply system widens the economical operating range of the diesel engine.
Low fuel consumption under common operating conditions, with a minimum specific fuel consumption of 195 g/kW·h.
Comfortable and Environmentally Friendly
Reinforced design of key components ensures low vibration and reduced noise levels.
Complies with IMO Tier II emission standards.
High Practicality
Incorporates a wave mode to ensure the vessel does not shut down during critical moments when encountering rough seas.
Large market population, abundant spare parts supply, and convenient maintenance.
产品规格
备注：产品参数及图片仅供参考；如有变动，不另行通知。
型谱表
|
Engine series |
Model |
Power(kW/Ps) |
Speed(r/min) |
Technical route |
Aspiration |
Emission |
Rating |
Fuel |
|
WD12 |
WD12C300-15 |
220/300 |
1500 |
Mechanical |
TA |
IMO Tier II |
P1 |
MGO |
| WD12 |
WD12C327-15 |
240/327 |
1500 |
Mechanical |
TA |
IMO Tier II |
P1 |
MGO |
| WD12 |
WD12C350-18 |
258/350 |
1800 |
Mechanical |
TA |
IMO Tier II |
P1 |
MGO |
| WD12 |
WD12C375-21 |
275/375 |
2150 |
Mechanical |
TA |
IMO Tier II |
P1 |
MGO |
| WD12 |
WD12C400-21 |
294/400 |
2150 |
Mechanical |
TA |
IMO Tier II |
P1 |
MGO |
Remark: The delivery date of model with * should be negotiated specifically
